VC2GE - 1/4" and 5/16" Valve Core Removal Tool Dual Valve with Sight Glass

Fieldpiece offers a versatile and rugged VC2GE to help you do your job easier, faster, and better.

- Integrated sight glass to verify engagement of valve core;
- Swappable 1/4" and 5/16" service port fittings
- Integrated dual valve to protect test gauges and use multiple hose lines
- Integrated comfort spinner for easier removal and insertion
- Vacuum-rated to 20 microns
- A2L compatible.

With our VC2GE, you can tackle any HVACR with efficiency, accuracy, and comfort all while always ensuring the engagement of the valve core.

Overview

Three reasons why you need the VC2GE

1. Accuracy is key

Know you've got it! The VC2GE comes equipped with an Integrated Sight Glass feature to ensure the HVACR engineer to verify that the valve core has been captured prior to closing the ball valve and removing the plunger assembly. Save time and improve the efficiency of your work with this accurate, brand new feature.

2. Versatile sidekick

Not only is the VC2GE accurate, but it is also super versatile. Swappable port fittings ensure the HVACR technician only needs one VCRT at every job, which reduces the number of tools you need to carry to the job site! The VC2GE has swappable port fittings between 1/4" and 5/16" available. And thanks to the o-ring sealing between the fitting and the VCRT body, you never have to worry about leaks.

3. Convenient on-site

The VC2GE is accurate, versatile, and efficient and now it's time to add convenience to this equation. By integrating the dual valve into the base of the VCRT, and thus creating our Integrated Dual Valve VCRT, The HVACR technician can be worry-free about leaks, and in complete control of the evacuation, recovery or charging of a system. On top of that, the comfort spinner, a free-spinning, rubberized cap, ensures less pain and injury on the hands while operating the VCRT. Plus, the overall size of your VCRT is smaller, so you can carry it everywhere on-site. Only take one VCRT on-site: the VC2GE!

Specifications

Product

  • A2L Compatible
  • Vacuum rating: 20 microns / 0.027 millibar / 0.020 Torr
  • Maximum working pressure: 55 Bar / 800 psi
  • Dimensions: 128.52 mm x 66.802 mm x 38.1 mm
  • Weight: 272 g

Included in package

  • 1/4″ Female service port fitting standard, 5/16” fitting included
  • 1/4” Male side port with removable valve core
