Job Link® Training

Your Name

Name

1. A customer asks "Can I still view my measurements if I am 200 meters away from the tools using Job Link®?" - your answer is:

A. Up to 300 meters line of sight

B. Yes, but only up 200 meters line of sight is possible

C. No, up to 100 meters line of sight is possible

D. No, Up to 50 meters line of sight is possible

2. A customer asks "which Job Link® products connect wirelessly to the SMAN® manifold?" - Your answer is:

A. No Job Link® enabled products can connect to the SMAN® Manifold

B. All Job Link® enabled products can connect to the SMAN® Manifold

C. The JL3RH Psychrometers, the SR47 Scales, the MG44 Vacuum Gauge and the JL3LC or JL3PC Pipe Temperature Clamps can all connect to the SMAN® Manifold

D. The JL3PR Pressure Probes, the JL3MN Manometers and the DRX3 Leak Detector can connect to the SMAN® Manifold

3. A customer asks "how long can you data log with the JL3RH psychrometer?" - Your answer is:

A. Up to 24 hours of data logging is possible

B. Up to 200 hours of data loggins is possible

C. Up to 7 days of data logging is possible

D. You can not data log using the JL3RH Psychrometer

4. How many jobs can be recorded via the SMAN® manifold?

A. The SMAN® Manifold has the possibility to data log up to 9 jobs

B. The SMAN® Manifold has the possibility to data log up to 5 jobs

C. It is not possible to data log using the SMAN® Manifold

D. The SMAN® Manifold has the possibility to data log up to 50 jobs

5. A customer asks which model of Fieldpiece clamp meter is Job Link® enabled? - Your answer is:

A. The SC260 is Job Link® Compatible

B. Only the SC480 is Job Link® compatible

C. Both the SC480 and SC680 are Job Link® compatible

D. All of the Fieldpiece clamp meters are Job Link® compatible

6. If a customer requires to measure a system that is using DC voltage, and would like to measure a DC Amperage, which Fieldpiece multimeter would be required?

A. The SC260 would be required

B. The SC480 would be required

C. The SC680 would be required

D. None of the Fieldpiece Clamp Meter range can measure DC Amperage

7. If a customer is asking for a Fieldpiece Clamp Meter that can do Phase Rotation, which FP multimeter would be required?

A. The SC260 would be required

B. The SC480 or SC680 would be required

C. None of the Fieldpiece Clamp Meter range can measure phase rotation

D. All of the Fieldpiece clamp meters can measure phase rotation

8. Which model of FP leak detector is Job Link® enabled?

A. The DR58 is Job Link® compatible

B. Only the DRX3 is Job Link® compatible

C. Both the DR82 and DR58 are Job Link® compatible

D. None of the Fieldpiece leak detectors are Job Link® compatible

9. A customer asks for a leak detector that can detect R32, tracer gas and R290, which Fieldpiece Leak Detector model would you be able to offer them?

A. The DR58

B. The DR82

C. The DRX3

D. Any Fieldpiece Leak Detector, they detect all refrigerants

10. A customer is looking for a vacuum gauge that can withstand positive pressures up to 50 Bar. - Your answer is:

A. The Fieldpiece Vacuum Gauges are not suitable for this application

B. Only the MG44 Vacuum Gauge can withstand a positive pressure of up to 60 Bar

C. Only the in-built Vacuum Gauge in the SMAN® can withstand a positive pressure of up to 60 Bar

D. Both the MG44 and in-built Vacuum Gauge in SMAN® can withstand a positive pressure of up to 60 Bar

11. A customer asks when he would start seeing a micron reading on the MG44 vaccum gauge? - Your answer is:

A. 25,000 Microns

B. 20,000 Microns

C. 15,000 Microns

D. 10,000 Microns

12. A customer asks why an external vacuum gauge is important, when there is already one built into the SMAN® manifold that he/she owns. Your answer is:

A. It's safer to have a back-up gauge in case one goes faulty

B. You can see the information on the screen easier on the MG44

C. The MG44 can be placed at the furthest point in the system to ensure the best vacuum reading is obtained

D. The MG44 is not important, and the customer does not need one if they already own an SMAN® manifold

13. A customer asks what the main application of using an JL3MN is? - Your answer is:

A. To measure water temperature differential on a water cooled system

B. To measure the airflow of the system

C. To measure gas/static pressures of a ducted system

D. To take refrigerant pressure measurements of a HVAC system

14. A customer asks what the advantage is of using the JL3MN versus using the SDMN5 Fieldpiece Manometer. - Your answer is:

A. The JL3MN has a better accuracy than the SDMN5

B. The JL3MN is able to take the measurements without hoses

C. The JL3MN is able to become a Dual Port Manometer that can split in two - meaning less hose length to the system and easier placement

D. There are no advantages of the JL3MN over the SDMN5

15. A customer asks what they can measure using the JL3RH? - Your answer is:

A. Pipe temperatures and pressures of a system

B. Dry Bulb and Wet Bulb Temperature, Relative Humidity %, Dew Point and Enthalpy

C. Dry Bulb only

D. Wet Bulb only

16. An engineer asks whether the Fieldpiece JL3RH is designed to take both liquid and air temperature measurements? - Your answer is:

A. Yes, however only the tip of the JL3RH can be submerged into water

B. Yes, but only liquid temperatures up to 50 degrees celsius

C. No - the JL3RH can not be used to measure liquid temperatures, it is designed for air temperatures only

D. No - The JL3RH is designed for measuring pipe temperature only

17. An engineer states that he commonly works on 1 5/8" pipework and is looking to take a temperature of the pipe, which product would you recommend? - Your answer is:

A. The JL3LC

B. The JL3PC

C. The JL3RH

D. The JL3PR

18. A customer asks what the advantage of the Rapid Rail™ Sensor is on our JL3LC or JL3PC? - Your answer is:

A. The Fieldpiece Rapid Rail™ system means that pipe temperature measurements are stable within 3 seconds

B. Won't give false readings due to wind, heat, corrosion or paint work/insulation on pipes

C. Pipe surface actually becomes part of the sensor for best in class measurements

D. All of the above

19. A customer asks "Can I use the Job Link® app to measure the temperatures of 3 indoor AC units at the same time in a hotel?" What is your answer?

A. No, the Job Link® application can not be customised to see more than one system at a time

B. No, however there are additional paid for subscription features that can enable mutliple system measurements

C. Yes, this is possible by customising the measurements screen to measure 3 Air Side containers with 3 sets of Job Link® tools

D. Yes, but you would need to have three phones or tablets to view the measurements

20. A customer asks if they need to pay a subscription to use the Job Link® application? Your answer should be:

A. Yes, to be able to use the Job Link® application you must pay a subscription fee

B. No, however there are additional paid for subscription features like invoicing and job reporting

C. Yes, but only if you want to add your company logo to the report

D. No, The Fieldpiece Job Link® application does not have any paid for subscription services
