Have a question? Your answer might be here.
Frequently Asked Questions
If your question has not been answered, please let us know by using the form on the support page.
JobLink® Application
How many devices can connect to one tool?
There is no limit to the amount of devices that can connect wirelessly to our JobLink® enabled tools.
Can I save my measurement report to the cloud?
Yes, with JobLink® PRO you can save your measurement reports to the cloud.
Can I add notes to my measurement reports?
Yes, you can quickly and easily add customised notes to the JobLink® measurement report.
Can I update a JobLink® tool?
Yes, when your JobLink® tool requires an update the app will guide you through the update process.
How many tools can I display at once?
Electrical clamp meter, SC480/SC680: 1 at a time......................................................................................................................................................................................................................................................................................................................................................
Manometer, JL3MN: 8 at a time (4 set to P1, 4 set to P2)......................................................................................................................................................................................................................................................................................................................................................
Psychrometer, JL3RH: 16 at a time (8 set to Return, 8 set to Supply)......................................................................................................................................................................................................................................................................................................................................................
Pressure probe, JL3PR: 8 at a time (4 set to Suction, 4 set to Liquid)......................................................................................................................................................................................................................................................................................................................................................
Temperature Clamp, JL3PC/JL3LC: 8 at a time (4 set to Suction, 4 set to Liquid)......................................................................................................................................................................................................................................................................................................................................................
Manifold, SM380V/SM480V: 4 at a time......................................................................................................................................................................................................................................................................................................................................................
Vacuum gauge, MG44/SM380V/SM480V: 1 at a time......................................................................................................................................................................................................................................................................................................................................................
Scale, SRS3/SRS3EC/SR47INT: 1 at a time......................................................................................................................................................................................................................................................................................................................................................
Can I upload attachment to my JobLink® report?
Yes, with the JobLink® PRO subscription you can easily attach document and images to the measurement report.
Can I measure the performance of a system?
Yes, you can measure both COP and EER with the JobLink® app.
Can I view customer and equipment history in the JobLink® app?
Yes, with the JobLink® PRO subscription you can easily view customer and equipment history.
Can I create a tightness/vacuum test report using the JobLink® app?
Yes, you can easily generate measurement reports and the outcome of thightness/vacuum tests using the free JobLink® app.
Can I create job reports and save them by location?
Yes, with the JobLink® PRO subscription you can create, sort and save jobs by location.
What is the difference between the free version of the JobLink® app and the JobLink® PRO subscription?
JOB LINK® free......................................................................................................................................................................................................................................................................................................................................................
After 60 days trial period......................................................................................................................................................................................................................................................................................................................................................
Live Measurements......................................................................................................................................................................................................................................................................................................................................................
Advanced Calculations......................................................................................................................................................................................................................................................................................................................................................
Systems Diagnostics......................................................................................................................................................................................................................................................................................................................................................
Email Your Measurements......................................................................................................................................................................................................................................................................................................................................................
JOB LINK® PRO......................................................................................................................................................................................................................................................................................................................................................
Everything included in the Joblink free version plus:......................................................................................................................................................................................................................................................................................................................................................
System Measurement Reports (Email & Print)......................................................................................................................................................................................................................................................................................................................................................
Cloud Storage......................................................................................................................................................................................................................................................................................................................................................
Inspection Checklists......................................................................................................................................................................................................................................................................................................................................................
Photos and Notes......................................................................................................................................................................................................................................................................................................................................................
Customer and Equipment History......................................................................................................................................................................................................................................................................................................................................................
Build Teams......................................................................................................................................................................................................................................................................................................................................................
Live Look-in......................................................................................................................................................................................................................................................................................................................................................
Is the JobLink® app free to download?
Yes, the JobLink® app is free to download. You get a JobLink® PRO 60 day trial. After 60 days you get the option to continue with the JobLink® PRO subscription or revert to the free version.
How do I create a JobLink® account?
When you install the JobLink® app you will be guided through the "create an account" process.
Can I use the dataloging feature without JobLink®?
Yes, you can also use the datalogging feature on the SMAN® Digital Manifold.
What tools connect to JobLink®?
MG44, SC480, SC680, SM480VINT, SM380VINT, JL3LC, JL3MNINT, JL3RHINT, JL3PRINT, JL3PCINT, SRS3EC, SRS3 & SR47INT.
The JobLink® app is showing incorrect measurement values, what do I do?
If your JobLink® app is showing incorrect values, it could be that you have one or more of the tools connected to a system, and you need to choose which one you should connect to. Ensure you are connected to the correct tool by cross referencing the serial number from the tool and what is shown on the JobLink® app.
The JobLink® app doesn't connect to my tools, what do I do?
1. Ensure that the tools you are trying to connect to are within the wireless range (300 meters) and turned on.
2. Ensure that the JobLink® application has both Bluetooth and location services permission from the mobile/tablet device.
3. Tap on 'Link tool' to bring up the list of tools available to connect to.
4. Connect to the right type of box, where you want the tool to appear.
DR58EU - Heated Diode Refrigerant Leak Detector
Why is my leak detector alarming?
If no sensor is installed or the installed sensor is faulty when the unit is turned on, an alarm will sound and the unit will turn off.
What is the difference between automatic zero and manual zero?
Automatic zeroing on the instrument allows for convenient pinpointing of a refrigerant leak by setting a new 'zero-value' every 3-4 seconds. This is useful when a large concentration of refrigerant is being detected in a contained area. Manual zeroing puts the control of the zero function in your hands, you can simply press the zero button on the tool at any time to set a new zero value. This is good for clarifying the leak source once it has been identified.
How do I use low/medium/high?
Set the sensitivity level by pressing the Sensitivity button. Low (L), medium (M), or high (H) sensitivity will be indicated at the top of the LCD display. The higher the concentration of refrigerant in the ambient air, the lower the sensitivity setting should be to minimize false trips.
What is the difference between the DR58 and DR82?
The DR58 uses a heated diode sensor. The heated diode’s advantage is that it detects absolute concentration levels so it can be held on a leak and will continue to beep. It is also initially very sensitive. Its disadvantage is that the sensor becomes less sensitive over life, eventually needing replacement.
The DR82 uses an infrared (IR) sensor. It detects a change in concentration, so the wand must keep moving. The advantage of the Fieldpiece IR sensor and its sensitivity is that it will last the lifetime of the instrument.
How do I replace the sensor?
First you need to order a new replacement sensor "RHD1". To replace the sensor, make sure the unit is turned off. Unscrew the wand on the DR58 and gently pull the sensor from the base. Now you can install the new sensor and put it back together.
DR82EU - Infrared Refrigerant Leak Detector
What is the difference between the DR58 and DR82?
The DR58 uses a heated diode sensor. The heated diode’s advantage is that it detects absolute concentration levels so it can be held on a leak and will continue to beep. It is also initially very sensitive. Its disadvantage is that the sensor becomes less sensitive over life, eventually needing replacement.
The DR82 uses an infrared (IR) sensor. It detects a change in concentration, so the wand must keep moving. The advantage of the Fieldpiece IR sensor and its sensitivity is that it will last the lifetime of the instrument.
What is the difference between automatic zero and manual zero?
Automatic zeroing on the instrument allows for convenient pinpointing of a refrigerant leak by setting a new 'zero-value' every 3-4 seconds. This is useful when a large concentration of refrigerant is being detected in a contained area. Manual zeroing puts the control of the zero function in your hands, you can simply press the zero button on the tool at any time to set a new zero value. This is good for clarifying the leak source once it has been identified.
How do I use low/medium/high/turbo?
Set the sensitivity level by pressing the Sensitivity button. Low (L), medium (M), or high (H) sensitivity will be indicated at the top of the LCD display. The higher the concentration of refrigerant in the ambient air, the lower the sensitivity setting should be to minimize false trips. The TURBO (T) function is an additional 4th sensitivity that pushes the DR82 to it highest possible sensitivity.
How do I replace the sensor?
The DR82 does not require a replacement sensor, it will last the lifetime of the instrument.
How long does the sensor last?
The DR82 sensor will last the lifetime of the instrument.
JL3PCINT - Job Link® System Premium Pipe Clamp Probe
What pipe size can the clamp go up to?
It goes from 1/4" - 1 3/8".
Why does it show open when pipe clamp is closed?
When the pipe clamp shows open or the orange LED is blinking the pipe that the clamp is on may need to be cleaned. Remove the clamp and use the Emory cloth provided to clean the pipe and put clamp back on.
Why am I not getting a superheat or subcooling measurement?
There are three possibilities: ......................................................................................................................................................................................................................................................................................................................................................
1. No pressure probe connected. ......................................................................................................................................................................................................................................................................................................................................................
2. No pipe clamp connected. ......................................................................................................................................................................................................................................................................................................................................................
3. No refrigerant selected.
What is the wireless range?
300 meters line of sight.
Can my tool connect wirelessly to the manifold?
Yes, you can connect your tool to the manifold.
JL3LC - Job Link® System Large Pipe Clamp
What pipe size can the clamp go up to?
It goes from 3/4" - 4 1/8".
Why does it show open when pipe clamp is closed?
When the pipe clamp shows open or the orange LED is blinking the pipe that the clamp is on may need to be cleaned. Remove the clamp and use the Emory cloth provided to clean the pipe and put clamp back on.
Why am I not getting a superheat or subcooling measurement?
There are three possibilities: ......................................................................................................................................................................................................................................................................................................................................................
1. No pressure probe connected. ......................................................................................................................................................................................................................................................................................................................................................
2. No pipe clamp connected. ......................................................................................................................................................................................................................................................................................................................................................
3. No refrigerant selected.
What is the wireless range?
300 meters line of sight.
Can my tool connect wirelessly to the manifold?
Yes, you can connect your tool to the manifold.
JL3PRINT - Job Link® System Pressure Probe
What is the measurement range?
29" HgV to 580 psig (40 bar).
How can I "zero" my pressure probe?
The Fieldpiece JL3PR pressure probe sensor automatically calibrates to barometric pressure, so it is accurate at any elevation. There is no need to manually Zero the tool.
What size fitting is on the pressure probe?
The Connector Type is Standard 1/4" SAE ( 45° angled).
Why am I not getting a superheat or subcooling measurement?
There are three possibilities: ......................................................................................................................................................................................................................................................................................................................................................
1. No pressure probe connected. ......................................................................................................................................................................................................................................................................................................................................................
2. No pipe clamp connected. ......................................................................................................................................................................................................................................................................................................................................................
3. No refrigerant selected.
What is the wireless range?
300 meters line of sight.
Is the tool compatible with CO2?
Our JL3PR is compatible with CO2, however the maximum pressure range is 40 Bar.
Can my tool connect wirelessly to the manifold?
Yes, you can connect your tool to the manifold.
JL3RHINT - Job Link® System Flex Psychrometer Probe®
How many systems can I see at the same time?
You can see up to 8 different systems on the same screen in the JobLink app. However you can measure more than 8 by connecting the probes you will be using, and pushing the blue serial number next to the probe you would like to switch out and selecting the probe you would like to see.
What measurements are taken with the Fieldpiece JL3RH?
The JL3RH can measure the following: ......................................................................................................................................................................................................................................................................................................................................................
- Dry bulb ......................................................................................................................................................................................................................................................................................................................................................
- Wet bulb ......................................................................................................................................................................................................................................................................................................................................................
- %RH ......................................................................................................................................................................................................................................................................................................................................................
- Dew point ......................................................................................................................................................................................................................................................................................................................................................
- Enthalpy ......................................................................................................................................................................................................................................................................................................................................................
What is the wireless range?
300 meters line of sight.
Can my tool connect wirelessly to the manifold?
Yes, you can connect your tool to the manifold.
SM380VINT/SM480VINT - SMAN Refrigerant Manifold l Wireless
What other fieldpiece wireless products connect wirelessly to the manifold?
The SM480 and SM380 are compatible and can connect wirelessly to the following:
- JL3RH Psychrometer ......................................................................................................................................................................................................................................................................................................................................................
- JL3PC Pipe Clamp ......................................................................................................................................................................................................................................................................................................................................................
- JL3LC Large Pipe Clamp ......................................................................................................................................................................................................................................................................................................................................................
- SRS3 Weighing Scales ......................................................................................................................................................................................................................................................................................................................................................
- MG44 Vacuum Gauge ......................................................................................................................................................................................................................................................................................................................................................
- SRS3EC Weighing Scales .....................................................................................................................................................................................................................................................................................................................................................
- SRS47 Weighing Scales .....................................................................................................................................................................................................................................................................................................................................................
How do I clean my manifold?
Cleaning the Sensors in the manifold over time is required, the pressure sensors inside the manifold may become contaminated with dirt, oil, and other contaminants in normal operational use. To do so, please follow the guide below: ......................................................................................................................................................................................................................................................................................................................................................
1. Never use an object such as a cotton swab to clean the sensor, you may cause damage to the sensor. ......................................................................................................................................................................................................................................................................................................................................................
2. Open all valves and cap all the ports except for the VAC port on the SM480, or the central port on the SM380. ......................................................................................................................................................................................................................................................................................................................................................
3. Drop enough Isopropyl (rubbing) alcohol into the VAC/middle port using an eye dropper or funnel so that it can flush out contaminants. ......................................................................................................................................................................................................................................................................................................................................................
4. Cap VAC/middle port and gently shake your Manifold upside down to clean sensor.
......................................................................................................................................................................................................................................................................................................................................................
5. Turn right side up. Open a port to pour out the rubbing alcohol and open all ports to allow sensors to dry out. Drying usually takes about an hour. Repeat if necessary if issues persist.
Can I use the SM380/SM480 with A2L and A3 refrigerants?
The manifold has a list of over 70 common refrigerants used in refrigeration and air conditioning, and this includes A2L and A3 refrigerants. For the full list of refrigerants visit the product page.
Why does my vacuum pressure jump up when I turn off my vacuum pump?
The moisture inside the system is still boiling off and is no longer being taken out or compensated for by the vacuum pump.
There could be oil that is holding moisture inside either the hose leading to the manifold or inside the block of the manifold.
Why does my vacuum pressure jump up when I close my high side & low side?
You have isolated the micron gauge from the system, you are now only reading what is inside your manifold and the hose connected to vacuum pump.
What is the operating pressure range?
29" HgV to 800 psig/ 55 bar. 1-10.000 microns.
Why does my superheat/subcooling read -o/l?
You may have a negative degree of superheat or subcooling. To check this see below: ......................................................................................................................................................................................................................................................................................................................................................
1. Plug in thermocouple into LLT port and change refrigerant to R113 to check to see if the manifold calculates subcooling. ......................................................................................................................................................................................................................................................................................................................................................
2. Plug in thermocouple into LLT port and change refrigerant to R407F to check to see if the manifold calculates superheat.
Why is my vacuum pressure inaccurate?
Vacuum pressure being inaccurate is a sign of oil holding moisture either inside the block of the manifold or in the hoses. The oil in your vacuum pump may also need to be changed.
Clean sensor periodically with rubbing alcohol.
Why does it say "NSG" in the "THS - TargetSuperHeat" box?
It stands for “no signal” (NSG).
How to perform advance pressure calibration?
Advanced Calibration: ......................................................................................................................................................................................................................................................................................................................................................
1. Plug in thermocouple into SLT port. ......................................................................................................................................................................................................................................................................................................................................................
2. Calibrate Thermocouple to Ice water 0°C. ......................................................................................................................................................................................................................................................................................................................................................
3. Tape thermocouple to side of refrigerant tank that has been sitting at a constant temperature for 24-48 hours. ......................................................................................................................................................................................................................................................................................................................................................
4. Put a brass cap on SLT and another one on LLT and open up both valves. ......................................................................................................................................................................................................................................................................................................................................................
5. Hook up refrigerant tank to manifold and open the tank. (Ensure that the Vac valve is closed on manifold before opening refrigerant tank. 4 port manifold only.) ......................................................................................................................................................................................................................................................................................................................................................
6. Open refrigerant tank. ......................................................................................................................................................................................................................................................................................................................................................
7. Select the type of refrigerant being used for this on the manifold. ......................................................................................................................................................................................................................................................................................................................................................
8. Open up the Ref port on manifold (4 port manifold only). Both high and low pressures should read the same. ......................................................................................................................................................................................................................................................................................................................................................
9. Press “Test Cal” button. Both pressure sensors should read “GOOD”."
What is the wireless range?
300 meters line of sight.
Which refrigerants are compatible with the SM380VINT and SM480VINT manifolds?
A full list of refrigerants can be found in our user manual. Additional refrigerants can be uploaded to the manifold via regular software updates. Check our Software Update page on the website.
MG44INT - Wireless Vacuum Gauge
Can I connect the MG44 to the SMAN digital manifold?
Yes, the MG44 connects to our SM380/SM480. SM380/SM480 prior to production as of June 1, 2021 will require a firmware update in order to connect the MG44. The firmware update instructions are available on the Fieldpiece website, go to https://www.fieldpiece.com/download-software-firmware-updates/. Production after June 1, 2021 will include the newest firmware and does not require an update.
How can I read the measurements on the MG44?
There are three ways to view the measurements. ......................................................................................................................................................................................................................................................................................................................................................
1. On the LCD screen on the tool itself ......................................................................................................................................................................................................................................................................................................................................................
2. Wirelessly connected to the JobLink® application ......................................................................................................................................................................................................................................................................................................................................................
3. Wirelessly connected to the SMAN480/SMAN380 manifold ......................................................................................................................................................................................................................................................................................................................................................
Why is my vacuum pressure inaccurate?
Vacuum pressure being inaccurate is a sign of oil holding moisture either inside the sensor compartment or in the hose that the MG44 is connected to. The oil in your vacuum pump may also need to be changed.
Clean sensor periodically with rubbing alcohol.
How to clean/maintain my MG44?
Clean the sensor of the MG44 with rubbing alcohol. Do not stick anything into the sensor. Doing so will damage the sensor. Check the user manual for details.
Where is the best location to put the MG44 for most accurate vacuum pressure reading?
Ideally it is best to connect the MG44 to the furthest point in the system (away from the vacuum pump).
Why will my MG44 show vacuum pressure when directly hooked up to pump but not when I am pulling on a system?
Evacuation takes time. You are pulling a vacuum in a larger volume (Refrigeration system/AC system + vacuum pump) compared to just a vacuum pump. Check that there are no leaks in your hoses, change the oil of the vacuum pump, and perform a triple evacuation if there is an indication of a lot of moisture in the system.
How do I check if my MG44 is leaking or not?
Connect MG44 to empty recovery tank and using a vacuum pump pull down to 500 microns and isolate the pump from recovery tank. Microns should rise slowly and stabilize and not immediately rise.
Why does my vacuum pressure jump up when I turn off my vacuum pump?
The moisture inside the system is still boiling off and is no longer being taken out or compensated for by the vacuum pump. Allow sufficient time (this will depend on the volume of the system) for stabilization.
Why does my MG44 read – – – – ?
The MG44 has a measuring range between 50-25,000 microns. Anything outside of that range will show the 4 dashes – – – -. The bar graph will show a wider range from deep vacuum up to atmosphere.
What is the wireless range?
300 meters line of sight.
What is the maximum overpressure on the MG44?
The maximum overpressure for the MG44 is 60 bar (870psig)
Can my tool connect wirelessly to the manifold?
Yes, you can connect your tool to the manifold.
MR45INT/MR45UK - Digital Recovery Machine
Is the MR45INT/MR45UK dual voltage?
The MR45INT is 230v only, however we do sell the MR45UK which is 110v only.
How do I clean my recovery machine?
1. Wipe with damp cloth to clean the exterior. Do not use solvents. To extend the life of internal seals, occasionally pump a teaspoon of mineral oil through MR45. ......................................................................................................................................................................................................................................................................................................................................................
2. When the mesh screen filter becomes dirty and clogged, it means it’s keeping your MR45INT/MR45UK working well and protected from contaminants entering the machine and causing damage. You need to clean or replace this screen often.
What is the high pressure cut-out set to?
The High pressure cut out is set to 550 psi / 38 bar.
Do I need to use a filter drier?
We recommend to use a filter drier on the input port and change it often to protect the MR45INT/MR45UK from contaminated refrigerants.
Is the MR45INT/MR45UK A3 approved?
No, the MR45INT/MR45UK is not certified for A3 refrigerants, therefore it cannot be used with any combustible refrigerants.
Is the MR45INT/MR45UK A2L approved?
Yes, the MR45INT/MR45UK is A2L ready and can be used with refrigerants such as R32, R1234ZE and R1234YF.
What is the over pressure protection on the recovery machine?
The High-pressure cut off switch activates at 38 bar (550 psig). The MR45 also has a secondary protection which is an auto-reset mechanical pressure relief valve set at 45 bar (652 psig).
At what negative pressure will the recovery machine cut off?
20"hg negative pressure or 50cmHg negative pressure is the final recovery value when the machine will stop automatically.
VP67 / VP87 / VPX7 - Vacuum Pump
What's the difference between the VP67 / VP87 / VPX7?
VP67INT: 6 CFM 170 l/min - 13,15 kg - AC motor - Dual voltage ...................................................................................................................................................................................................................................................................................................................................................... VP87INT: 8 CFM 225 l/min - 12,25 kg - DC motor - 110V or 230V ...................................................................................................................................................................................................................................................................................................................................................... VPX7INT: 10 CFM 280 l/min - 10,9 kg - DC motor with EPO coating** - 110V or 230V
Why is there vapor coming out of the pump?
It is normal for the pump to emit vapor when pumping on a chamber from atmosphere. Since all the air that is removed from the chamber by the pump moves through the oil in the oil reservoir, some of that oil is vaporized when a lot of air is moving through it. When the pressure in the chamber is reduced to a few hundred torr, the oil vapor will be reduced.
How often do I need to change the oil?
We recommend to empty or replace oil at the end of every usage. Don’t leave old oil in the machine. Store the pump and oil in dry clean areas for longest life. The oil can lose its sealing properties if left uncovered. Keep the oil sealed until it’s ready for use.
Do I have to use fieldpiece oil?
No, you can use any manufacturer's vacuum pump oil, however fieldpiece oil is optimized for our vacuum pumps and has a specific viscosity for maximum performance.
Why is my oil cloudy?
Excessive moisture is present in the oil indicating that the oil needs to be replaced.
How do I know that my vacuum pump can pull down sufficiently?
Perform this test to ensure the vacuum pump and your micron gauge are working properly. ......................................................................................................................................................................................................................................................................................................................................................
1. Connect your vacuum gauge directly to a port on the vacuum pump. ......................................................................................................................................................................................................................................................................................................................................................
2. Seal the 3 other ports. ......................................................................................................................................................................................................................................................................................................................................................
3. Ensure the gas ballast is closed. ......................................................................................................................................................................................................................................................................................................................................................
4. Turn on the vacuum pump to create a vacuum at your gauge. ......................................................................................................................................................................................................................................................................................................................................................
If your gauge measures below 200 microns within 1 minute, you know the vacuum pump and your micron gauge are working correctly. If your gauge does not reach 200 microns, there is a problem with your gauge, the vacuum pump, or both.
What are the sizes of the ports?
The port sizes from left to right are 1/4”, 1/2”, 3/8”, 3/8“.
What is the gas ballast and when do I use it?
A gas ballast valve will allow a flow of air into the final part of the compression cycle and allow the vapor to be expelled without condensation or affecting the pump's overall performance. Using the gas ballast valve on the initial pull down helps the pump run smoothly and keeps the oil in good condition.
Can the vacuum pump pull a vacuum for A3/NH3 refrigerant systems?
The vacuum pumps are certified for A2L refrigerant systems. We do not certify the pump against A3 systems, or systems with NH3 - however, as long as the systems are completely void of refrigerant before evacuation, it can be used on those systems.
Does the Vacuum pump have an anti-suck back oil system?
Yes, The Fieldpiece Vacuum Pumps features a non-mechanical ‘anti-oil suck back’ system which when the machine loses power, will ensure that the oil in the vacuum pump does not migrate into the system or the hose lines.
We achieve this by having an ‘open-air’ valve that is sealed when the machine is running, but then slowly opens up to atmospheric pressure when the machine loses power or is switched off.
The issue we solve with this feature is the oil-suck back issue which can be very damaging and time consuming to the system should this happen.
What is the final recovery vacuum?
Final recovery vacuum is 14.9" HG
What type of oil is used with the machine?
Mineral oil
How many stages do the vacuum pumps have?
All our vacuum pumps (VP67/VP87/VPX7) have 2 stages.
SC260 - 400A Clamp Meter Compact
Is the SC260 a wireless tool?
No, the SC260 is not a wireless tool. However the SC480 and SC680 are wireless tools.
What is true-RMS
A true-RMS meter can accurately measure those imperfect, nonsinusoidal waves, as well as perfect, sinusoidal waves. “RMS” stands for root-mean-square, which is a calculation used to determine the equivalent DC value of an AC waveform. True RMS measurements are important to ensure that you can test variable frequency drives more accurately.
What is NCV?
NCV is an abbreviation for Non-Contact Voltage. Use NCV to check for 24VAC up to 600VAC. Always test on a known live source before using.
My meter shows "dISC", what does this mean?
If dISC is displayed, the capacitor is not discharged completely.
Does it have a fuse I can change?
No, our meters do not use a fuse you can change. They use a PTC-fuse (positive temperature coefficient) as it is faster and safer for the technician.
SC480INT - 600A Clamp Meter Dual Display | Power
What is the wireless range?
300 meters line of sight.
What is true-RMS
A true-RMS meter can accurately measure those imperfect, nonsinusoidal waves, as well as perfect, sinusoidal waves. “RMS” stands for root-mean-square, which is a calculation used to determine the equivalent DC value of an AC waveform. True RMS measurements are important to ensure that you can test variable frequency drives more accurately.
Does it have a fuse I can change
No, our meters do not use a fuse you can change. They use a PTC-fuse (positive temperature coefficient) as it is faster and safer for the technician.
SC680INT - 600 AC/DC Swivel Clamp Meter Dual Display l Power l LPF
What is the wireless range?
300 meters line of sight.
What is true-RMS?
A true-RMS meter can accurately measure those imperfect, nonsinusoidal waves, as well as perfect, sinusoidal waves. “RMS” stands for root-mean-square, which is a calculation used to determine the equivalent DC value of an AC waveform. True RMS measurements are important to ensure that you can test variable frequency drives more accurately.
Can I use the min/max to determine my inrush current?
No, the min/max button is not the same as inrush as it does not capture readings fast enough. For inrush current please use the 'inrush button' on the side of the instrument near the clamp meter head.
Does it have a fuse I can change?
No, our meters do not use a fuse you can change. They use a PTC-fuse (positive temperature coefficient) as it is faster and safer for the technician.
SRS3/SR47INT - Refrigerant Scale 114 kg Capacity l Wireless
Is the SRS3/SR47INT EC-tye approved?
The regular SRS3/SR47INT is not EC-type approved, however we do have the SRS3EC which is EC-type approved.
What is the wireless range?
300 meters line of sight.
Can I sync a second remote to my SRS3/SR47INT?
Yes, you can sync two SRS3/SR47INT remote displays to a single SRS3/SR47INT platform if desired. ......................................................................................................................................................................................................................................................................................................................................................
1. Press SYNC for 1 second. ......................................................................................................................................................................................................................................................................................................................................................
2. The ID# of a detected platform will show. (This ID# is printed on the platform.) ......................................................................................................................................................................................................................................................................................................................................................
3. Tap SYNC to cycle through any other platforms detected. ......................................................................................................................................................................................................................................................................................................................................................
4. Press SYNC for 1 second to select a platform.
What happens if I lose my remote?
If you lose the SRS3/SR47INT remote, please reach out to the Fieldpiece Distributor you purchased the product from, or fill out our form on the support page. https://fieldpiece-europe.com/support
Please note that the SRS3/SR47INT measurement values can still be seen on the JobLink® mobile application, as well as directly on the SM480 or SM380 manifold screen.
Can my tool connect wirelessly to the manifold?
Yes, you can connect your tool to the manifold.
SRS3EC - Refrigerant Scale EC 100 kg Capacity l Wireless
Can I sync a second remote to my SRS3EC?
No, in order to comply to the EC regulations, it is mandatory that the scale must only communicate with one remote at any one time.
What happens if I lose my remote?
If you lose the SRS3EC remote, please reach out to the Fieldpiece Distributor you purchased the product from, or fill out our form on the support page. https://fieldpiece-europe.com/support
Please note that the SRS3EC measurement values can still be seen on the JobLink® mobile application, as well as directly on the SM480 or SM380 manifold screen.
What is the wireless range?
300 meters line of sight.
Can my tool connect wirelessly to the manifold?
Yes, you can connect your tool to the manifold.
SDMN5 - Manometer Dual Port
My SDMN5 won’t turn on anymore how do I get it to turn on?
Take out the battery hold the power button for 45 seconds and reinstall battery. If this does not work the first time try again. If it sill won’t turn on, check to see if you have a good battery or fill out our form on the support page. https://fieldpiece-europe.com/support
Is the SDMN5 wireless to JobLink®?
No, for wireless manometer readings to the JobLink® application, please see the JL3MN wireless manometer.
SCL2EUR - Carbon Dioxide Leak Detector
When should I replace the filter?
If it seems like your leak detector is no longer picking up leaks or is not as sensitive as it was when you first bought it, replace the filter.
How do I replace the sensor?
The SCL2 does not require a replacement sensor, it will last the lifetime of the instrument.
How do I use low/medium/high/turbo
Set the sensitivity level by pressing the L/M/H button. Low (L), medium (M), or high (H) sensitivity will be indicated by the respective LEDs. The higher the concentration of refrigerant in the ambient air, the lower the sensitivity setting should be to minimize false trips. The TURBO function is an additional 4th sensitivity that pushes the SRL2 to it highest possible sensitivity. This feature is activated by pressing the PEAK button four times in succession, and can only be activated while on the high(H) sensitivity level. The TURBO function is an additional 4th sensitivity that pushes the SCL2 to it highest possible sensitivity. This feature is activated by pressing the PEAK button four times in succession, and can only be activated while on the high(H) sensitivity level.
